Texas Instruments TMS320C6745 DSP - Page 202

SYSCFG Registers www.ti.com
202
SPRUH91D–March 2013–Revised September 2016
Submit Documentation Feedback
Copyright © 2013–2016, Texas Instruments Incorporated
System Configuration (SYSCFG) Module
Table 10-29. Pin Multiplexing Control 7 Register (PINMUX7) Field Descriptions (continued)
Bit Field
ZKB
Ball
(1)
PTP
Pin
(2)
Value Description
15-12 PINMUX7_15_12 R6 17 SPI0_SOMI[0]/EQEP0I/GP5[0]/BOOT[0] Control
0 Pin is 3-stated.
1h Selects Function SPI0_SOMI[0]
2h Selects Function EQEP0I
3h-7h Reserved
8h Selects Function GP5[0]
9h-Fh Reserved
11-8 PINMUX7_11_8 K14 60 EMB_WE_DQM[0]/GP5[15] Control
0 Pin is 3-stated.
1h Selects Function EMB_WE_DQM[0]
2h-7h Reserved
8h Selects Function GP5[15]
9h-Fh Reserved
7-4 PINMUX7_7_4 C15 85 EMB_WE_DQM[1]/GP5[14] Control
0 Pin is 3-stated.
1h Selects Function EMB_WE_DQM[1]
2h-7h Reserved
8h Selects Function GP5[14]
9h-Fh Reserved
3-0 PINMUX7_3_0 F13 74 EMB_D[15]/GP6[15] Control
0 Pin is 3-stated.
1h Selects Function EMB_D[15]
2h-7h Reserved
8h Selects Function GP6[15]
9h-Fh Reserved
