System Configuration (SYSCFG) Module
Table 10-31. Pin Multiplexing Control 9 Register (PINMUX9) Field Descriptions (continued)
Bit Field
ZKB
Ball
(1)
PTP
Pin
(2)
Value Description
15-12 PINMUX9_15_12 C5 126 ACLKX0/ECAP0/APWM0/GP2[12] Control
0 Pin is 3-stated.
1h Selects Function ACLKX0
2h Selects Function ECAP0/APWM0
3h-7h Reserved
8h Selects Function GP2[12]
9h-Fh Reserved
11-8 PINMUX9_11_8 B5 125 AHCLKX0/AHCLKX2/USB_REFCLKIN/GP2[11] Control
0 Pin is 3-stated.
1h Selects Function AHCLKX0
2h Selects Function AHCLKX2
3h Reserved
4h Selects Function USB_REFCLKIN
5h-7h Reserved
8h Selects Function GP2[11]
9h-Fh Reserved
7-4 PINMUX9_7_4 E4 — USB0_DRVVBUS/GP4[15] Control
0 Pin is 3-stated.
1h Selects Function USB0_DRVVBUS
2h-7h Reserved
8h Selects Function GP4[15]
9h-Fh Reserved
3-0 PINMUX9_3_0 P4 8 SPI1_SCS[0]/UART2_TXD/GP5[13] Control
0 Pin is 3-stated.
1h Selects Function SPI1_SCS[0]
2h Selects Function UART2_TXD
3h-7h Reserved
8h Selects Function GP5[13]
9h-Fh Reserved
