Architecture www.ti.com
828
SPRUH91D–March 2013–Revised September 2016
Submit Documentation Feedback
Copyright © 2013–2016, Texas Instruments Incorporated
General-Purpose Input/Output (GPIO)
Table 20-1. GPIO Register Bits and Banks Associated With GPIO Signals (continued)
GPIO Pin Number GPIO Signal Name Bank Number Control Registers Register Bit Register Field
31 GP1[14] 1 register_name01 Bit 30 GP1P14
32 GP1[15] 1 register_name01 Bit 31 GP1P15
33 GP2[0] 2 register_name23 Bit 0 GP2P0
34 GP2[1] 2 register_name23 Bit 1 GP2P1
35 GP2[2] 2 register_name23 Bit 2 GP2P2
36 GP2[3] 2 register_name23 Bit 3 GP2P3
37 GP2[4] 2 register_name23 Bit 4 GP2P4
38 GP2[5] 2 register_name23 Bit 5 GP2P5
39 GP2[6] 2 register_name23 Bit 6 GP2P6
40 GP2[7] 2 register_name23 Bit 7 GP2P7
41 GP2[8] 2 register_name23 Bit 8 GP2P8
42 GP2[9] 2 register_name23 Bit 9 GP2P9
43 GP2[10] 2 register_name23 Bit 10 GP2P10
44 GP2[11] 2 register_name23 Bit 11 GP2P11
45 GP2[12] 2 register_name23 Bit 12 GP2P12
46 GP2[13] 2 register_name23 Bit 13 GP2P13
47 GP2[14] 2 register_name23 Bit 14 GP2P14
48 GP2[15] 2 register_name23 Bit 15 GP2P15
49 GP3[0] 3 register_name23 Bit 16 GP3P0
50 GP3[1] 3 register_name23 Bit 17 GP3P1
51 GP3[2] 3 register_name23 Bit 18 GP3P2
52 GP3[3] 3 register_name23 Bit 19 GP3P3
53 GP3[4] 3 register_name23 Bit 20 GP3P4
54 GP3[5] 3 register_name23 Bit 21 GP3P5
55 GP3[6] 3 register_name23 Bit 22 GP3P6
56 GP3[7] 3 register_name23 Bit 23 GP3P7
57 GP3[8] 3 register_name23 Bit 24 GP3P8
58 GP3[9] 3 register_name23 Bit 25 GP3P9
59 GP3[10] 3 register_name23 Bit 26 GP3P10
60 GP3[11] 3 register_name23 Bit 27 GP3P11
61 GP3[12] 3 register_name23 Bit 28 GP3P12
62 GP3[13] 3 register_name23 Bit 29 GP3P13
63 GP3[14] 3 register_name23 Bit 30 GP3P14
64 GP3[15] 3 register_name23 Bit 31 GP3P15
65 GP4[0] 4 register_name45 Bit 0 GP4P0
66 GP4[1] 4 register_name45 Bit 1 GP4P1
67 GP4[2] 4 register_name45 Bit 2 GP4P2
68 GP4[3] 4 register_name45 Bit 3 GP4P3
69 GP4[4] 4 register_name45 Bit 4 GP4P4
70 GP4[5] 4 register_name45 Bit 5 GP4P5
71 GP4[6] 4 register_name45 Bit 6 GP4P6
72 GP4[7] 4 register_name45 Bit 7 GP4P7
73 GP4[8] 4 register_name45 Bit 8 GP4P8
74 GP4[9] 4 register_name45 Bit 9 GP4P9
75 GP4[10] 4 register_name45 Bit 10 GP4P10
76 GP4[11] 4 register_name45 Bit 11 GP4P11
77 GP4[12] 4 register_name45 Bit 12 GP4P12
