Memory Protection Unit (MPU)
Table 5-7. Memory Protection Unit 2 (MPU2) Registers (continued)
Address Acronym Register Description Section
01E1 5200h PROG1_MPSAR Programmable range 1 start address register Section 5.3.10.2
01E1 5204h PROG1_MPEAR Programmable range 1 end address register Section 5.3.11.2
01E1 5208h PROG1_MPPA Programmable range 1 memory protection page attributes register Section 5.3.12
01E1 5210h PROG2_MPSAR Programmable range 2 start address register Section 5.3.10.2
01E1 5214h PROG2_MPEAR Programmable range 2 end address register Section 5.3.11.2
01E1 5218h PROG2_MPPA Programmable range 2 memory protection page attributes register Section 5.3.12
01E1 5220h PROG3_MPSAR Programmable range 3 start address register Section 5.3.10.2
01E1 5224h PROG3_MPEAR Programmable range 3 end address register Section 5.3.11.2
01E1 5228h PROG3_MPPA Programmable range 3 memory protection page attributes register Section 5.3.12
01E1 5230h PROG4_MPSAR Programmable range 4 start address register Section 5.3.10.2
01E1 5234h PROG4_MPEAR Programmable range 4 end address register Section 5.3.11.2
01E1 5238h PROG4_MPPA Programmable range 4 memory protection page attributes register Section 5.3.12
01E1 5240h PROG5_MPSAR Programmable range 5 start address register Section 5.3.10.2
01E1 5244h PROG5_MPEAR Programmable range 5 end address register Section 5.3.11.2
01E1 5248h PROG5_MPPA Programmable range 5 memory protection page attributes register Section 5.3.12
01E1 5250h PROG6_MPSAR Programmable range 6 start address register Section 5.3.10.2
01E1 5254h PROG6_MPEAR Programmable range 6 end address register Section 5.3.11.2
01E1 5258h PROG6_MPPA Programmable range 6 memory protection page attributes register Section 5.3.12
01E1 5260h PROG7_MPSAR Programmable range 7 start address register Section 5.3.10.2
01E1 5274h PROG7_MPEAR Programmable range 7 end address register Section 5.3.11.2
01E1 5268h PROG7_MPPA Programmable range 7 memory protection page attributes register Section 5.3.12
01E1 5270h PROG8_MPSAR Programmable range 8 start address register Section 5.3.10.2
01E1 5274h PROG8_MPEAR Programmable range 8 end address register Section 5.3.11.2
01E1 5278h PROG8_MPPA Programmable range 8 memory protection page attributes register Section 5.3.12
01E1 5280h PROG9_MPSAR Programmable range 9 start address register Section 5.3.10.2
01E1 5284h PROG9_MPEAR Programmable range 9 end address register Section 5.3.11.2
01E1 5288h PROG9_MPPA Programmable range 9 memory protection page attributes register Section 5.3.12
01E1 5290h PROG10_MPSAR Programmable range 10 start address register Section 5.3.10.2
01E1 5294h PROG10_MPEAR Programmable range 10 end address register Section 5.3.11.2
01E1 5298h PROG10_MPPA Programmable range 10 memory protection page attributes register Section 5.3.12
01E1 52A0h PROG11_MPSAR Programmable range 11 start address register Section 5.3.10.2
01E1 52A4h PROG11_MPEAR Programmable range 11 end address register Section 5.3.11.2
01E1 52A8h PROG11_MPPA Programmable range 11 memory protection page attributes register Section 5.3.12
01E1 52B0h PROG12_MPSAR Programmable range 12 start address register Section 5.3.10.2
01E1 52B4h PROG12_MPEAR Programmable range 12 end address register Section 5.3.11.2
01E1 52B8h PROG12_MPPA Programmable range 12 memory protection page attributes register Section 5.3.12
01E1 5300h FLTADDRR Fault address register Section 5.3.13
01E1 5304h FLTSTAT Fault status register Section 5.3.14
01E1 5308h FLTCLR Fault clear register Section 5.3.15
