Nokia 9500 MPR - Figure 751 Lockout Spare Core-E Card

Perform protection switching
1006
WebEML User Manual
Figure 751 Lockout Spare Core-E Card
To release a Switch on a Core Card
1. Select Main or Spare Core card in the resource tree area. See Figure 752.
2. On the Commands tab, from the New Value drop-down menu, select None.
3. Click Apply.
The Switch confirmation window displays.
4. Click OK.
Caution: Releasing Forced switch Core will cause a hit to traffic.
Release 7.0.0 3DB 19286 ACAA Issue 01
