Nokia 9500 MPR - Figure 603 MPT-HL Additional Settings Tab

WebEML User Manual Configure radio parameters
801
Figure 603 MPT-HL Additional Settings tab
33. Provision MPT-HL radio link identifier:
i. Select the Link Identifier Configuration Enabled check box.
ii. Enter the Expected Identifier value (0 to 255).
iii. Enter the Sent Identifier value (0 to 255).
iv. Click Apply.
34. Provision the MPT-HL Synchronization Status Messaging
i. Select the Synchronization SSM Enabled check box; see Figure 603.
ii. Click Apply.
Note: If the MPT-HL is part of a LAG, you cannot change the SSM, PKT throughput booster,
or PPP settings on an individual radio. Go to Administer L1/L2 radio and L2 Ethernet LAG
ports to administer LAG ports.
Release 7.0.0 3DB 19286 ACAA Issue 01
