WebEML User Manual Enable equipment
483
Figure 299 P8ETH enabled
5. Verify port segregation provisioning. Port segregation should be provisioned
between the P8ETH Ethernet ports and other Ethernet and/or radio ports where
connectivity is not desirable. See Provision port segregation/connectivity for
detailed steps to view/provision port segregation.
To enable an EASv2 card
1. Select MSS-n/Slot# (slot 3 through 8) in the resource tree area where the
EASv2 card will be enabled. The selected slot will highlight in blue. This
selection also highlights the selected slot in blue on the graphical representation
of the MSS shelf in the resource list area. See Figure 300.
Release 7.0.0 3DB 19286 ACAA Issue 01
