Nokia 9500 MPR - Figure 335 Enable the MPT-HLS Radio

WebEML User Manual Enable equipment
519
Figure 335 Enable the MPT-HLS radio
4. Click on one of the vertical slots of the subrack.
5. In the Settings panel, choose MPT-HLS from the Equipment Type drop-
down.
6. Choose one of the ports on the EASv2 card from the Interface drop-down.
7. Click on the Apply button. An SD check box is displayed.
8. If the diversity combiner is in use, select the SD check box and click on the
Apply button.
9. The card is enabled. The fan slot is outlined in red.
To enable an MPT-HLS fan
1. See Figure 336 and follow the steps to enable the fan.
To enable the fan:
iv
v vi vii
23758
