Nokia 9500 MPR - Figure 715 Main Equipment Window: PDH E1;DS1 Transponder Card Highlighted

To Next Page

To Previous Page

WebEML User Manual Core Facing PDH/SDH Tributary Loopback

953

1. In the main equipment window, double-click the PDH/SDH Transponder Card

associated with the tributary to perform Core Facing PDH/SDH Tributary

Loopback. For E1/DS1 loopback, see Figure 715. For DS3 loopback, see

Figure 716. For SDH loopback, see Figure 717.

Figure 715 Main Equipment Window: PDH E1/DS1 Transponder Card highlighted

Release 7.0.0 3DB 19286 ACAA Issue 01
