Nokia 9500 MPR - Figure 764 Manual Rx Radio Switch: Main Radio Channel to Spare Radio Channel

WebEML User Manual Perform protection switching
1019
Figure 764 Manual Rx Radio Switch: Main Radio Channel to Spare Radio Channel
To perform a Manual Rx Radio Switch from the Spare to the Main Radio Channel
1. Select Protection Schemes/Slot#/Rx Radio Protection/Spare#0 in the
resource tree area. See Figure 765.
2. On the Commands tab, from the New Value drop-down menu, select Manual.
3. Click Apply.
The Switch confirmation window displays.
4. Click OK.
Caution: Manual Rx Radio switching equipment will cause a hit to traffic.
Release 7.0.0 3DB 19286 ACAA Issue 01
