Nokia 9500 MPR - Figure 375 Disabled MPTACC

To Next Page

To Previous Page

WebEML User Manual Disable equipment

561

Figure 375 Disabled MPTACC

To disable an auxiliary card

1. Select MSS-n/Slot#8 in the resource tree area where the Auxiliary card will be

disabled. The selected slot will highlight in blue. This selection also highlights the

selected slot in blue on the graphical representation of the MSS shelf in the

resource list area. See Figure 376.

Release 7.0.0 3DB 19286 ACAA Issue 01
