Nokia 9500 MPR - Figure 329 Resource List Area: P8 ETH Selected

To Next Page

To Previous Page

WebEML User Manual Enable equipment

513

2. Click the Settings Tab in the resource detail area. See Figure 329.

3. From the Port Usage drop-down menu, select port usage type MPT-HC, MPT-

MC, or MPT-HQAM.

Figure 329 Resource list area: P8ETH selected

4. Click Apply. The P8ETH card will populate the selected port #. See Figure 330.

Release 7.0.0 3DB 19286 ACAA Issue 01
