Nokia 9500 MPR - Figure 625 Provisioned MPT-HLS 1+1 Vertical XPIC Radio Channel

WebEML User Manual Configure radio parameters
833
Figure 625 Provisioned MPT-HLS 1+1 Vertical XPIC radio channel
23. Select an action.
a. To Provision the MPT-HLS manual transmit power level (RTPC), go to
step 38.
b. To Provision the MPT-HLS Automatic Transmit Power Control (ATPC), go
to step 43.
24. Provision the MPT-HLS radio protection type
From the Equipment tab, select the MPT-HLS Dir#-Ch1 in the resource tree
area. The selected name will highlight in blue. This selection also highlights the
MPT-HLS transceiver icon in blue in the resource list area.
Note: Spare MPT-HLS transceiver must be enabled prior to provisioning MPT-HLS
transceiver protection scheme.
Release 7.0.0 3DB 19286 ACAA Issue 01
