Perform protection switching
1014
WebEML User Manual
Figure 759 Manual HSB Switch: Main Radio Channel to Spare Radio Channel
To perform a Manual HSB Switch from the Spare to Main Radio Channel
1. Select Protection Schemes/Slot#/HSB Protection/Spare#0 in the resource
tree area. See Figure 760.
2. On the Commands tab, from the New Value drop-down menu, select Manual.
3. Click Apply.
The Switch confirmation window displays.
4. Click OK.
Caution: Manual HSB switching equipment will cause a hit to traffic.
