Provision Ethernet Ring Protection (ERP)
574
WebEML User Manual
Figure 386 Add PDH VLAN IDs to ERP Instance
3. Add PDH VLAN IDs to Ethernet Ring cross-connections. For detailed steps to
add PDH to Ring cross-connections, see Provision cross connections.
To add a radio flow to an ERP instance
1. Add Radio flows to ERP Instance using the following procedure:
See Figure 386 for the following steps:
a. Select ERP instance to add Radio flows.
b. Enter Radio flow VLAN IDs in Add VLANS text field.
c. Click >>.
d. VLAN IDs are added to the VLAN ID table.
e. Click Apply.
2. Add Radio VLAN IDs to Ethernet Ring cross-connections. For detailed steps to
add Radio to Ring cross-connections, see Provision cross connections.
To add an Ethernet flow to an ERP instance
1. To add an Ethernet flow to an ERP instance
Add MEF8 Ethernet flows to ERP Instance using the following procedure:
See Figure 386 for the following steps:
a. Select ERP instance to add Ethernet flows.
b. Enter MEF8 Ethernet flow VLAN IDs in Add VLANS text field.
c. Click >>.
d. VLAN IDs are added to the VLAN ID table.
e. Click Apply.
Release 7.0.0 3DB 19286 ACAA Issue 01
