Enable equipment

510

WebEML User Manual

Figure 326 Enabled MPT-HC ODU on Core-E optical SFP Ethernet port

6. Go to step 9.

7. From the Port # (1-4) Usage drop-down menu, select port usage type MPT-HC,

MPT-MC or MPT-HQAM. See Figure 327.

Release 7.0.0 3DB 19286 ACAA Issue 01
