Nokia 9500 MPR - Figure 632 MPT-HLS Transceiver Protection Criteria Provisioning

WebEML User Manual Configure radio parameters
843
Figure 632 MPT-HLS transceiver protection criteria provisioning
49. Select Equipment Protection in the resource tree area.
i. From the Restoration Criteria panel, verify the Restoration Criteria selection
and provision if required:
ii. Select the Not Revertive or Revertive radio button.
iii. Click Apply.
50. Select HSB Protection in the resource tree area.
51. From the Restoration Criteria panel, verify the Restoration Criteria selection and
provision if required:
i. Select the Not Revertive or Revertive radio button.
ii. Click Apply.
Danger: For 1+1 FD protection type, HSB Protection is not available.
