Nokia 9500 MPR - Figure 423 Node K to Node B (Protected): PDH-Ring Cross-Connection on Node B

WebEML User Manual Provision cross connections in a mixed fiber/
microwave Ring
613
Figure 423 Node K to Node B (protected): PDH-Ring cross-connection on Node B
a. Choose the flow IDs to cross-connect from the Available VLANs list
b. Choose the Service profile: TDM2TDM or TDM2ETH
c. Choose the Clock Source, if the Service profile is TDM2ETH
d. Enter the Ring Destination MAC address: Node D Unicast MAC address
2. Configure a pass-through cross-connection on Node A, see Figure 424.
Note: The Ring Destination MAC address on Node B can be either the Unicast MAC
address of Node D or that of Node A. However, the configuration on Node B affects the
configuration on other nodes in the fiber chain.
Release 7.0.0 3DB 19286 ACAA Issue 01
