Nokia 9500 MPR - Figure 612 Provisioned MPT-HLC 1+1 Vertical XPIC Radio Channel

WebEML User Manual Configure radio parameters
811
Figure 612 Provisioned MPT-HLC 1+1 Vertical XPIC radio channel
23. Select an action.
a. To Provision the MPT-HLC manual transmit power level (RTPC), go to
step 42.
b. To Provision the MPT-HLC Automatic Transmit Power Control (ATPC), go
to step 44.
24. Configure the MPT-HLC radio protection type
From the Equipment tab, select the MPT-HLC Dir#-Ch1 in the resource tree
area. The selected name will highlight in blue. This selection also highlights the
MPT-HLC transceiver icon in blue in the resource list area.
Note: Spare MPT-HLC transceiver must be enabled prior to provisioning MPT-HLC
transceiver protection scheme.
Release 7.0.0 3DB 19286 ACAA Issue 01
