Configure radio parameters
818
WebEML User Manual
b. To Provision the MPT-HLC Automatic Transmit Power Control (ATPC), go
to step 44.
38. Provision the MPT-HLC manual transmit power level (RTPC)
Open the appropriate radio main view depending on your radio configuration
and select the Settings tab; see Figure 614.
39. Provision MPT-HLC radio channel transmit power level:
i. Choose the TxPower (dBm) level for the lowest modulation scheme in the
range. Power levels for the other modulation schemes will be set
automatically.
ii. Click Apply.
40. Select an action.
a. To Provision the spare MPT-HLC RTPC, go to step 42.
b. To Provision the MPT-HLC radio protection scheme, go to step 48.
41. Provision the spare MPT-HLC RTPC
Open the appropriate radio main view depending on your radio configuration
and select the Settings tab; see Figure 616.
42. Provision Spare MPT-HLC radio channel transmit power level:
i. Choose the TxPower (dBm) level for the lowest modulation scheme in the
range. Power levels for the other modulation schemes will be set
automatically.
ii. Click Apply.
43. Provision the MPT-HLC Automatic Transmit Power Control (ATPC)
Open the appropriate radio main view depending on your radio configuration
and select the Settings tab; see Figure 617.
Release 7.0.0 3DB 19286 ACAA Issue 01
