Nokia 9500 MPR - Figure 249 Delete Per-VLAN Per-Cos Rate Limiting

Provision Ethernet ports
424
WebEML User Manual
a. Select Ethernet Port#n to provision (Ethernet Port #1/#8).
b. Select Per-VLAN Per-CoS Rate Limiter tab.
c. Click on the Create button.
d. Select the VLAN ID from the VLAN drop-down menu.To identify the rate
limiter by the PCP only, select Any.
e. Select the PCP from the PCP drop-down menu.
f. Select the Ingress CIR size (Kbit/s) [0 Kbit/s to 1Gbit/s].
Select the Ingress Max Burst (KByte) [4 KBytes to 16 KBytes, in steps of
powers of 2].
Click on the Apply button.
To delete Per-VLAN Per-CoS rate limiting
1. Delete Per-VLAN Per-CoS Rate Limiter parameters using the following
procedure. See Figure 249.
Figure 249 Delete Per-VLAN Per-CoS rate limiting
a
c
b
23044
d e
Release 7.0.0 3DB 19286 ACAA Issue 01
