WebEML User Manual Provision equipment port
435
Figure 254 Provision CorEvo Sync-In/Out SFP port
4. Click Apply.
The SFP is ready to be configured as Sync-In and Sync-Out ports. See
Administer synchronization.
To provision Sync-In/Out SFP on MSS-1
1. Select Slot #1 MSS/CORE in the resource tree area. The selected name will
highlight in blue. This selection also highlights the MSS-1 in blue in the resource
list area.
2. Click the Settings Tab in the resource detail area. See Figure 255 for an
example.
Release 7.0.0 3DB 19286 ACAA Issue 01
