Nokia 9500 MPR - Figure 633 MPT-HLS Additional Settings Tab

Configure radio parameters
844
WebEML User Manual
52. Select Rx Radio Protection in the resource tree area.
53. From the Restoration Criteria panel, verify the Restoration Criteria selection and
provision if required:
i. Select the Not Revertive or Revertive radio button.
ii. Select the Physical Cable check box in the RPS Configuration area if an
RPS cable is in use.
iii. Click Apply.
54. Provision the MPT-HLS link identifier
Open the appropriate radio main view depending on your radio configuration
and select the Additional Settings tab; see Figure 633.
Figure 633 MPT-HLS Additional Settings tab
55. Provision MPT-HLS radio link identifier:
i. Select the Link Identifier Configuration Enabled check box.
Release 7.0.0 3DB 19286 ACAA Issue 01
