View alarms
258
WebEML User Manual
7. Click Done to save the filter. Click Cancel to close Save Filters As window and
discard the selections.
To load Alarm Manager Filters
1. From the Alarm Manager Main Menu Bar, select Filters>Load Filters From.
The Load Filters From window opens. See Figure 146.
Figure 146 Alarm Manager Load Filters From window
2. Click Browse and navigate to the folder where the filter file is located.
3. Select the filter file to load.
4. Click Open.
5. From the scope pane, select NE to load filter.
6. From the Loaded Filters pane, select filter to load.
7. Optionally, enter a prefix in the Filters Name Prefix field to prefix the characters
to the filter name. Example, enter <Dal>, the name of the loaded filter changes
from APT to DalAPT.
8. Click Done to load filter to selected NE. Click Cancel to close Load Filters From
window and discard all selections.
Release 7.0.0 3DB 19286 ACAA Issue 01
