Disable equipment

554

WebEML User Manual

Figure 368 Deprovision MPT-HC from Core-E electrical Ethernet port

7. Click Apply.

The Core MPT ODU port will display empty and the MPT ODU is removed from

the resource list area. See Figure 369.

Release 7.0.0 3DB 19286 ACAA Issue 01
