Enable equipment
478
WebEML User Manual
• To enable an auxiliary card
• To enable an MPT-HLS radio
• To enable an MPT-HLS fan
• To enable an MSS Fan Unit
To enable a spare Core card
1. To enable a spare Core card
Select MSS-n/Slot#2 in the resource tree area. The selected slot will highlight
in blue. This selection also highlights slot #2 in blue on the graphical
representation of the MSS shelf in the resource list area. See Figure 294.
Figure 294 Select slot 2 to enable spare Core-E
2. Click the Settings Tab in the resource detail area.
3. From the Equipment Type drop-down menu, select CORE-ENH or CorEvo. See
Figure 295.
