Nokia 9500 MPR - Figure 584 MPT-HL or MPT-HLC Transceiver Settings Tab; 58 Provision Protection Type

To Next Page

To Previous Page

WebEML User Manual Provision Protection Type

773

Figure 584 MPT-HL or MPT-HLC Transceiver Settings tab

3. From the Protection Type drop-down menu, select: no Protection, 1+1 HSB/

SD, or 1+1 FD protection type.

4. Click Apply.

Protection information updating window opens.

5. Click OK.
