Administer external alarm points on an MSS-1 or
Enhanced Fan card
118
WebEML User Manual
16.4 Procedure
1. Select action.
2. To Open MSS External Input Point main view for MSS-1, go to step 4.
3. To Open MSS FANS Main View for MSS-8, go to step 6.
4. Open MSS External Input Point main view for MSS-1
Select MSS/HK in the resource tree area. This selection should also highlight
the Housekeeping inputs area in blue on the graphical representation of the
MSS-1 unit in the resource list area. The MSS External Input Point main view
opens, see Figure 36.
5. To Provision external alarm input, go to step 7.
6. Open MSS FANS Main View for MSS-8
Select Slot #9 MSS/FANS in the resource tree area. This selection should also
highlight the FAN card in blue on the graphical representation of the MSS-8 shelf
in the resource list area. The MSS A-FANS or E-FANS Main View opens. The
view is the same as shown in Figure 36.
7. Provision external alarm input
From the MSS FANS main view or MSS External Input Point main view, click the
Settings tab. See Figure 36.
8. Select CPI#[11-14] in the resource tree area.
Release 7.0.0 3DB 19286 ACAA Issue 01
