WebEML User Manual Provision equipment port
441
4. Click Apply.
The SFP port will populate port 4.
5. Verify port segregation provisioning. Port segregation should be provisioned
between the SFP Ethernet port and other Ethernet and/or radio ports where
connectivity is not desired. See Provision port segregation/connectivity for
detailed steps to view/provision port segregation.
To provision an E1 P32E1DS1 port
1. Click on the P32E1DS1 card or MSS/E1 in the resource list area.
The PDH Main View displays. See Figure 261.
Figure 261 PDH main view (ETSI market)
2. Provision E1 port using the following procedure:
Resource Tree Area: displays the tributary
ports sorted by the channel number
Resource List Area: displays tabular information
about the selected resource in the tree area
Resource Detail Area:
displays through tab
windows, the selected
object’s properties
in list area. This area
performs the available
functions for
involved resource
22998
Release 7.0.0 3DB 19286 ACAA Issue 01
