Digital Core Facing Loopback

962

WebEML User Manual

• To deactivate a Digital Core Facing Loopback

To activate a Digital Core Facing Loopback

1. In the main equipment window, double-click on the Transceiver radio icon to

perform Digital Core Facing Loopback. See Figure 722.

Figure 722 Main Equipment window: Radio icon highlighted

The main view for the selected radio direction opens.

2. Select the Maintenance tab. See Figure 723.

Release 7.0.0 3DB 19286 ACAA Issue 01
