WebEML User Manual Provision cross connections
363
Figure 198 Configuration Cross Connection window
2.
Verify port segregation provisioning. Port segregation should be provisioned
between parallel radio paths at both ends when they exist on the NE. Also port
segregation should be provisioned between the radio port and other Ethernet
and/or radio ports where connectivity is not desirable. See Provision port
segregation/connectivity for detailed steps to view/provision port segregation.
To provision a PDH to Radio Cross connection
1. Select PDH port and drag to draw line to RADIO port.
PDH-RADIO pop-up displays. See Figure 199.
Caution: When parallel radio paths exist between two MSS shelves, port
segregation should be provisioned between the parallel radio paths at both ends
to prevent a loss of traffic.
Release 7.0.0 3DB 19286 ACAA Issue 01
