Nokia 9500 MPR - Procedures; Figure 57 Qos Configuration Icon

Administer QoS configuration
148
WebEML User Manual
19.3 Procedures
This section provides the following procedures:
• To launch the QoS Configuration tool
• To provision the Queue Scheduling algorithm
• To restore Queue Scheduling algorithm default values
• To restore Saved Queue Scheduling algorithm values
• To provision Queue Size
• To restore Queue Size default values
• To restore saved Queue Size values
• To open the Qos Classification tool to administer QoS Classification
• To provision QoS Classification Criterion
• To provision 802.1p PCP to Internal Forwarding Class values
• To provision DiffServ DSCP to Internal Forwarding Class Values
• To restore 802.1p or DiffServ to Forwarding Class Default Values
• To restore Saved Queue Size values
To launch the QoS Configuration tool
1. Launch QoS Configuration tool from the craft terminal. Click the QoS
Configuration Icon, see Figure 57, or from the main menu bar, select
Configuration > QoS Configuration.
Figure 57 QoS Configuration icon
QoS Configuration tool opens. See Figure 58.
