Nokia 9500 MPR - Figure 439 Node I to NE G (Protected): Pass-Through Cross-Connection on Node B

WebEML User Manual Provision cross connections in a mixed fiber/
microwave Ring
629
Figure 439 Node I to NE G (protected): pass-through cross-connection on Node B
a. Choose the flow IDs to cross-connect from the Available VLANs list
b. Choose the Service profile: TDM2TDM or TDM2ETH
c. Choose the Clock Source, if the Service profile is TDM2ETH
d. Enter the Ring East MAC address: NE G Multicast MAC address
e. Enter the Ring West MAC address: Node A Unicast MAC address
5. Configure a pass-through cross-connection on Node D, see Figure 440.
