Provision cross connections
370
WebEML User Manual
3. On the STM-1_RADIO LAG pop-up, click OK.
The completed cross-connection appears (see Figure 204).
The priority of the SDH flows must be configured in the LAG; see Administer
SDH LAG.
Figure 204 Completed SDH to LAG cross-connection
4. On the Cross Connection screen, click Apply.
5. From the Connections tab, verify the SDH_RADIO LAG cross-connection was
entered correctly.
To provision an Ethernet to Radio Cross Connection
Caution: When parallel radio paths exist between two MSS shelves, port
segregation should be provisioned between the parallel radio paths at both ends
to prevent a loss of traffic.
