WebEML User Manual Disable equipment
529
Figure 343 Disabled MPT-HL or MPT-HLC transceiver
To disable an MPT-HL or MPT-HLC transceiver card on Core
1. Select the slot where the MPT-HL/MPT-HLC is equipped in the resource tree
area. The selected name will highlight in blue. This selection also highlights the
main Core-E card in blue on the graphical representation of the MSS shelf in the
resource list area.
2. Click the Settings Tab in the resource detail area. See Figure 344.
