Provision equipment port
444
WebEML User Manual
clock recovery, either adaptive or differential. After the first port on a
card is provisioned, all remaining ports on the card will default to the
clock recovery method selected on the first port.
j. From the TDM Clock Source drop-down menu, select TDM Clock Source:
Adaptive or Differential.
k. Enter the unique ECID Tx value.
l. Enter the unique ECID Rx value.
m. Click Apply.
Figure 263 Provision P32E1DS1 port
The PDH Main View updates adding the provisioned DS1 port to the
resource list area. See Figures Figure 264 and Figure 265.
b
c
e
f
g
d
j
h
k
l
a
m
23047
