28. Select an action.
a. To Provision the MPT-HLS radio for fixed modulation, go to step 29.
b. To Provision the MPT-HLS radio for adaptive modulation, go to step 32.
29. Provision the MPT-HLS radio for fixed modulation
Open the appropriate radio main view depending on your radio configuration
and select the Settings tab; see Figure 627.
Figure 627 MPT-HLS Settings tab for fixed modulation
30. Provision MPT-HLS radio port:
i. In the Mode field, select the Preset button.
Note: Depending on the modem profile selected, the Tx power may become out of range.
If this occurs, provision the Tx power to the desired level or to one supported by the modem
profile to clear the warning message.
