Nokia 9500 MPR - Figure 387 OAM Switching Criteria

WebEML User Manual Provision Ethernet Ring Protection (ERP)
577
Provision the Hold Off timer for any Ethernet ports in the ERP Instance. For
detailed steps, see Provision Ethernet ports.
To provision ETH OAM switching criteria (optional)
1. To provision ETH OAM switching criteria (optional)
To enable ETH OAM switching criteria, select the OAM Switch Criteria check
box, see Figure 387.
Figure 387 OAM switching criteria
Note: The OAM Switch Criteria check box only appears if User Ethernet ports are part of
the Ring.
Release 7.0.0 3DB 19286 ACAA Issue 01
