Safety awareness
52
WebEML User Manual
1.3.4 Equipment connection to earth
1.3.4.1 Labeling:
Terminals for equipment connection to earth, to be done according to international
safety standards, are pointed out by the symbol in Figure 6.
Figure 6 Equipment connection to earth
1.3.4.2 Safety instructions:
The position of earth connection terminals is specified in the Hardware Installation
section.
1.3.5 Heat-radiating mechanical parts
1.3.5.1 Labeling:
The presence of heat-radiating mechanical parts is indicated by the warning label in
Figure 7 in compliance with IEC 417 Norm, Fig.5041:
Figure 7 Heat-radiating mechanical parts
