WebEML User Manual Provision cross connections in a mixed fiber/
microwave Ring
595
Figure 402 Node J to Node K: pass-through cross-connection on Node D
a. Choose the flow IDs to cross-connect from the Available VLANs list
b. Choose the Service profile: TDM2TDM or TDM2ETH
c. Choose the Clock Source, if the Service profile is TDM2ETH
d. Enter the Ring Destination MAC address: Node A Unicast MAC address
e. Enter the Ring Source MAC address: Node D Unicast MAC address
To provision a cross-connection between Node J and Node D
1. One traffic end point belongs to the fiber chain, see Figure 403.
Release 7.0.0 3DB 19286 ACAA Issue 01
