Open and run performance monitoring
982
WebEML User Manual
To run PM on an Ethernet port
1. From the resource tree area, select the Ethernet Statistics pane.
2. From the Ethernet Statistics pane, expand the card tree and select the Ethernet
port on which to run Ethernet PM.
3. Click Stopped to start the monitoring. Figure 738 shows PM on an Ethernet port.
Figure 738 Ethernet port PM
Release 7.0.0 3DB 19286 ACAA Issue 01
