Nokia 9500 MPR - Figure 758 Forced HSB Switch Main Radio Channel

WebEML User Manual Perform protection switching
1013
Figure 758 Forced HSB Switch Main Radio Channel
To perform a Manual HSB Switch from the Main to Spare Radio Channel
1. Select Protection Schemes/Slot#/HSB Protection/Main#1 in the resource
tree area. See Figure 759.
2. On the Commands tab, from the New Value drop-down menu, select Manual.
3. Click Apply.
The Switch confirmation window displays.
4. Click OK.
Caution: Forced HSB switching equipment will cause a hit to traffic.
Release 7.0.0 3DB 19286 ACAA Issue 01
