Nokia 9500 MPR - Figure 668 Core Configuration Screen Example

To Next Page

To Previous Page

Use the Provisioning Tool

894

WebEML User Manual

iii. If autonegotiation is disabled, select a fixed speed and direction pair in the

“Speed - Duplex” area.

iv. If autonegotiation is enabled, Synch-E can be configured: choose

Synchronous and select the operating mode: Master or Slave. The SSM

(Synchronization Status Message) message can also be enabled.

Figure 668 Core Configuration screen example

Note: The Provisioning Tool does not distinguish between MPT-HC or MPT-HC-

HQAM and their -XP variants. For example, to configure an MPT-XP-HQAM

choose MPT-HQAM.

Note: MPT-MC appears in the drop-down menu. The MPT-MC unit is not used in North

America.

Release 7.0.0 3DB 19286 ACAA Issue 01
