Nokia 9500 MPR - Figure 336 Enable the MPT-HLS Fan

Enable equipment
520
WebEML User Manual
Figure 336 Enable the MPT-HLS fan
1. Click on the horizontal slot above the radio slots.
2. In the settings panel, choose SR-FAN4 from the Equipment Type drop-
down.
3. Choose an EAS channel from the Fan Handler MPTs drop-down.
4. Click Apply.
i
ii
v
iii
iv
23759
Release 7.0.0 3DB 19286 ACAA Issue 01
