Nokia 9500 MPR - Figure 350 Enabled Easv2

To Next Page

To Previous Page

Disable equipment

536

WebEML User Manual

Figure 350 Enabled EASv2

2. Click the Settings Tab in the resource detail area.

3. From the Equipment Type drop-down menu, select EMPTY. See Figure 351.

Release 7.0.0 3DB 19286 ACAA Issue 01
