Administer synchronization
336
WebEML User Manual
To enable 1588 Transparent Clock
1. Select Synchronization tab.
2. Select Synchronization Source in the resource tree area.
3. Select the 1588 tab in the resource detail area.
The 1588 tab displays. See Figure 185.
Figure 185 1588 tab
4. Select the Enabled check box.
5. Click on the Apply button.
The 1588 Transparent Clock is enabled.
To provision Synchronization — Master
1. Select the Synchronization tab.
Release 7.0.0 3DB 19286 ACAA Issue 01
