Nokia 9500 MPR - Figure 114 Network Elements List Window: Current NE Added

Administer NE list
222
WebEML User Manual
To add an NE to a List by first logging in to the NE
1. From the NEtO Overview window, log in to the NE to add to the NE list.
2. From the Network Elements List window, click Get Current. See Figure 114.
The NE currently logged in to is added to the NEs table.
Figure 114 Network Elements List window: Current NE added
3. Click Save.
Save window opens.
4. Click Save.
File already existing. Overwrite? window opens.
5. Click Yes.
File saved window opens.
6. Click OK.
To add an NE to a list by entering NE IP address
Note: The NE Table data is not automatically updated. If the NE details are updated (Site
Name, Site Location, Version, or IP Address) the NE Table data must be manually updated
or deleted and reloaded. The NE Table data is used for reference purposes only, the
operator must keep the data current.
Release 7.0.0 3DB 19286 ACAA Issue 01
