Nokia 9500 MPR - Figure 219 Radio to Ring Cross Connection

Deprovision cross connections
390
WebEML User Manual
Figure 219 Radio to Ring cross connection
2. On the RADIO-RING pop-up, select ERP Instance to deprovision cross
connection.
3. On the RADIO-RING pop-up, select Crossconnected VLANs to be
deprovisioned.
4. On the RADIO-RING pop-up, click <<.
5. Repeat steps 3 and 4 to deprovision additional Radio to Ring cross-connections
on this ERP Instance.
6. On the RADIO-RING pop-up, click OK.
7. On the Cross Connection screen, click Apply.
To deprovision an Ethernet to Ring cross connection
1. Double-click on the ETH to RING port line.
ETH-RING pop-up displays. See Figure 220.
Release 7.0.0 3DB 19286 ACAA Issue 01
