Nokia 9500 MPR - Figure 395 Remove Tx Mute to Node a

Upgrade a Ring to R5.1.0 software
586
WebEML User Manual
Figure 395 Remove Tx mute to Node A
10. Activate the R5.1.0 software on Node A, the RPL owner, see Figure 396. TDM
and Ethernet traffic entering Node A is protected by the Ring when the radio
interfaces toward Nodes B and D go down. When the upgrade is completed, and
after the WTR time has expired, the RPL owner puts the Ring in Idle state.
Release 7.0.0 3DB 19286 ACAA Issue 01
