Nokia 9500 MPR - Figure 516 NE F to Node C: Ethernet-Ring Cross-Connection on Node B

WebEML User Manual Provision cross connections in a mixed fiber/
microwave Ring
701
Figure 516 NE F to Node C: Ethernet-Ring cross-connection on Node B
a. Choose the flow IDs to cross-connect from the Available VLANs list
b. Choose the Service profile: TDM2TDM or TDM2ETH
c. Choose the Clock Source, if the Service profile is TDM2ETH
d. Enter the Destination MAC address: NE F Unicast MAC address
3. Configure a Radio-Ring or PDH-Ring cross-connection on Node C, see
Figure 517 and Figure 518.
Release 7.0.0 3DB 19286 ACAA Issue 01
